Heil Quaker ICP 1186255 Run Capacitor
The Heil Quaker ICP 1186255 is a high-performance round dual run capacitor engineered for heavy-duty HVACR applications. Ratings of 70/7.5 MFD (microfarads) at 440VAC allow this component to support both the compressor and condenser fan motor simultaneously, streamlining service calls and reducing the footprint within the electrical cabinet. This OEM-spec unit is a direct drop-in for legacy part numbers 1186420, P291-7073RS, and 1172295, frequently found in ICP-manufactured systems like Heil, Comfortmaker, and Tempstar. Built with a non-PCB biodegradable synthetic oil dielectric and a robust drawn steel case, it maintains stable capacitance across an operating temperature range of -40?C to 70?C. For field safety, the 1186255 includes a physical pressure-sensitive interrupter and quad-blade quick connect terminals marked for C, FAN, and HERM, ensuring accurate wiring. When you are performing a capacitor replacement, this 440 volt dual run capacitor provides the necessary voltage overhead to withstand line spikes that often cause premature failure in 370V alternatives.
Key Benefits- Direct OEM Compatibility: Specifically designed as an ICP 1186255 replacement to fit existing mounting brackets in Heil and Carrier-family condensing units.
- Heavy-Duty Voltage Tolerance: Rated for 440Vac, offering superior protection against electrical stress compared to standard 370V units.
- Integrated Safety Shutdown: Features an internal pressure interrupter to disconnect the circuit in the event of an internal fault.
- Efficient Dual Output: The 70+7.5 MFD configuration eliminates the need for separate start/run components for the compressor and fan.
- Contractor-Grade Construction: Oil-filled aluminum/steel housing ensures optimal heat dissipation during peak summer operation.
Can I use the 1186255 to replace a 370V capacitor?
Yes, a 440V capacitor is a superior technical upgrade for an existing 370V rating, as it provides a higher dielectric strength while maintaining the required 70/7.5 MFD capacitance.
What does the "70/7.5" rating represent in my diagnosis?
The 70 MFD side (HERM) provides the phase shift for the compressor, while the 7.5 MFD side (FAN) supports the condenser fan motor, allowing a single component to manage both loads.
Is this capacitor compatible with non-Heil brands?
While engineered for ICP brands, this unit is compatible with any HVAC system requiring a 70/7.5 MFD 440V/370V round capacitor, provided the physical dimensions match your mounting strap.
Item is Non Cancelable / Non Returnable
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
Original: $27.25
-65%$27.25
$9.54Heil Quaker ICP 1186255 Run Capacitor
The Heil Quaker ICP 1186255 is a high-performance round dual run capacitor engineered for heavy-duty HVACR applications. Ratings of 70/7.5 MFD (microfarads) at 440VAC allow this component to support both the compressor and condenser fan motor simultaneously, streamlining service calls and reducing the footprint within the electrical cabinet. This OEM-spec unit is a direct drop-in for legacy part numbers 1186420, P291-7073RS, and 1172295, frequently found in ICP-manufactured systems like Heil, Comfortmaker, and Tempstar. Built with a non-PCB biodegradable synthetic oil dielectric and a robust drawn steel case, it maintains stable capacitance across an operating temperature range of -40?C to 70?C. For field safety, the 1186255 includes a physical pressure-sensitive interrupter and quad-blade quick connect terminals marked for C, FAN, and HERM, ensuring accurate wiring. When you are performing a capacitor replacement, this 440 volt dual run capacitor provides the necessary voltage overhead to withstand line spikes that often cause premature failure in 370V alternatives.
Key Benefits- Direct OEM Compatibility: Specifically designed as an ICP 1186255 replacement to fit existing mounting brackets in Heil and Carrier-family condensing units.
- Heavy-Duty Voltage Tolerance: Rated for 440Vac, offering superior protection against electrical stress compared to standard 370V units.
- Integrated Safety Shutdown: Features an internal pressure interrupter to disconnect the circuit in the event of an internal fault.
- Efficient Dual Output: The 70+7.5 MFD configuration eliminates the need for separate start/run components for the compressor and fan.
- Contractor-Grade Construction: Oil-filled aluminum/steel housing ensures optimal heat dissipation during peak summer operation.
Can I use the 1186255 to replace a 370V capacitor?
Yes, a 440V capacitor is a superior technical upgrade for an existing 370V rating, as it provides a higher dielectric strength while maintaining the required 70/7.5 MFD capacitance.
What does the "70/7.5" rating represent in my diagnosis?
The 70 MFD side (HERM) provides the phase shift for the compressor, while the 7.5 MFD side (FAN) supports the condenser fan motor, allowing a single component to manage both loads.
Is this capacitor compatible with non-Heil brands?
While engineered for ICP brands, this unit is compatible with any HVAC system requiring a 70/7.5 MFD 440V/370V round capacitor, provided the physical dimensions match your mounting strap.
Item is Non Cancelable / Non Returnable
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
